Dual-port 10G SFP+ NIC with MUCSE RNP N10 controller for secure, high-performance networking.
When securing sensitive data streams in domestic infrastructure projects, relying on foreign controllers creates compliance risks. The LRES1031PF-2SFP+ network adapter addresses this by utilizing the indigenous MUCSE RNP N10 controller with independent intellectual property rights.
This dual-port 10G SFP+ card delivers 10Gbps per port via PCIe 3.0 x8, enabling high-throughput encrypted transmission without CPU bottlenecks. Integrated hardware offloads for IPsec and packet filtering enhance security processing efficiency, while DPDK support optimizes packet forwarding for virtualized environments.
Ideal for government servers and network security equipment requiring autonomous controllability, this adapter ensures national information security. With support for Galaxy Unicorn and NeoKylin OS, it provides a reliable, localized alternative to standard Ethernet solutions for critical deployments.
Based on MUCSE RNP N10 with independent IP rights for national information security and autonomous controllability.
Two 10G SFP+ ports deliver high-bandwidth optical fiber access for servers and security appliances.
Reconfigurable processor core handles IPsec, RSS, TSO, and checksum offloading to reduce CPU load.
Enhanced DPDK support enables efficient and flexible packet forwarding for virtualized network functions.
Compatible with Galaxy Unicorn, NeoKylin, and Tongxin UOS for localized infrastructure deployment.
Complete technical details for integration and deployment planning.
| Controller Chip | MUCSE RNP N10 |
|---|
| Bus Type | PCIe v3.0 (8.0GT/s) x8; compatible with x16 |
|---|---|
| Cable Medium | Optical Fiber |
| Connector | 2*10G SFP+ |
|---|---|
| Data Rate Per Port | 10Gbps |
| Fiber Type Support | 10GBASE-SR/ 10GBASE-LR/10GBASE-Cu, 1GBASE-SR/ 1GBASE-LR /1GBASE-Cu |
| Power Supply | PCIe |
|---|---|
| Power (min) | 6.852W |
| Power (max) | 8.520W |
| Protocol Support | IEEE 802.3ae, IEEE 802.3z, IEEE 802.3x, IEEE 802.1AS, IEEE 802.1Q, IEEE 802.3AD, IEEE 802.3az, IEEE 802.1P, IEEE 802.3ac |
|---|
| Feature Support (Yes) | DPDK, Jumbo Frames, VMDq, SR-IOV, IPsec Offload, Network Virtualization (VEB/VLAN/QinQ/VxLAN/NVRGE) |
|---|
| Feature Support (No) | PXE, WoL, iSCSI, FCoE |
|---|
| Operating Temperature | 0℃ to 70℃ (-32 ℉ to 158 ℉) |
|---|---|
| Storage Temperature | -55 ℃ to 105 ℃ (-67 ℉ to 221 ℉) |
| Storage Humidity | Maximum: 90% non-condensing relative humidity at 35 ℃ |
| ESD Contact Discharge | ±8KV (Class A) |
| Certification | FCC, CE, RoHS |
| Bracket Height | Low Profile & Full Height |
|---|---|
| PCB Size (mm) | 161.47*68.89*1.6 |
| Package Size (mm) | 222*147*28 |
| OS Compatibility | Galaxy Unicorn v10, NeoKylin 7.6, Centos 7.3/7.6/7.9/8.2/8.3, RHEL/CentOS 7.6, Ubuntu 18.04.5/20.04.1, ZTE New Fulcrum 3.2.2/5.0.5, Tongxin UOS20 |
|---|
Look up product firmware versions, hardware revisions, and OS compatibility by entering your part number or hardware version.
