Connect U.2 PCIe NVMe SSDs to M.2 slots for enhanced system performance.
Upgrading storage in legacy systems or slot-limited desktops often forces a choice between capacity and speed. The LRNV5611 M.2 to U.2 NVMe Adapter Card solves this by bridging the gap between modern U.2 enterprise SSDs and standard M.2 host interfaces, eliminating the need for costly motherboard replacements.
Featuring an M.2 Connector interface and SFF-8643 drive connector, this adapter supports one U.2 PCIe NVMe SSD via a PCIe 3.0 x4 host interface. This configuration delivers superior data transfer rates typical of enterprise-class drives, boosting overall system responsiveness and throughput for demanding applications.
Ideal for IT professionals and system integrators upgrading servers or workstations, this compact 80mm*22mm card ensures easy installation. By leveraging existing M.2 slots, it offers a seamless, high-performance storage expansion path for data-intensive tasks, maximizing hardware investment efficiency.
Add U.2 PCIe NVMe SSD performance to your desktop computer or server by connecting a U.2 SSD to an M.2 PCIe x4 host interface.
Adapter supports one U.2 PCIe NVMe SSD with a Mini-SAS HD SFF-8643 connector.
Simply connects to your computer and enables you to connect a U.2 SSD to your PC through the PCIe 3.0 x4 slots.
Delivers the superior performance of newer U.2 NVMe SSDs without the expense of replacing the system motherboard.
Complete technical details for integration and deployment planning.
| Model | LRNV5611 |
|---|---|
| Interface | M.2 Connector |
| Compatible Drive Type | U.2 (PCIe_NVMe SSD, SFF-8639) |
| Drive Connectors | SFF-8643 |
|---|
| Dimension | 80mm*22mm |
|---|---|
| Product Weight | 7g |
| Humidity | 15% ~ 90% |
|---|---|
| Operating Temperature | 5°C to 50°C (41°F to 122°F) |
| Storage Temperature | -25°C to 70°C (-13°F to 158°F) |
| Warranty | 2 Years |
|---|
