Converts SFF-8654 interface to two M.2 PCIe SSD slots for high-speed storage expansion.
The LRNVF512 is a specialized SFF-8654 to dual M.2 NVMe adapter card designed for high-performance storage expansion. It features a PCIe 4.0 x8 bandwidth with theoretical transfer speeds up to 128Gbps, converting one SFF-8654 host bus into two M.2 (PCIe, M-Key, NGFF) connectors. This driver-free solution maximizes SSD potential by eliminating interface bottlenecks.
Ideal for data centers, cloud computing, and AI training clusters, this adapter enables scalable storage upgrades in enterprise servers. By supporting high-speed, low-latency NVMe protocols, it meets rigorous demands for capacity and throughput in modern infrastructure. The compact design ensures efficient integration into dense server environments.
Operating reliably from 0°C to 70°C, the LRNVF512 offers robust thermal management and power efficiency. Its plug-and-play nature simplifies deployment for OEMs and system integrators seeking reliable storage scaling solutions. Backed by a two-year warranty, it ensures long-term stability for critical applications.
Supports NVMe standard protocol for high speed, low latency, and low power consumption operations.
Converts one SFF-8654 interface to two M.2 PCIe SSD slots, maximizing storage density.
Utilizes PCIe 4.0 x8 bandwidth with theoretical transfer speeds up to 128Gbps.
Plug-and-play functionality requires no additional drivers, simplifying installation and maintenance.
Complete technical details for integration and deployment planning.
| Model | LRFCF512 |
|---|---|
| Host Interface | 1x SFF-8654 Connector |
| Device Interfaces | 2x M.2 (PCIe, M-Key, NGFF) Connectors |
| Bus Bandwidth | PCIe 4.0 x8 |
| Theoretical Speed | Up to 128Gbps |
| Supported Protocol | NVMe Standard |
| Driver Requirement | No Driver Required |
| Dimensions | 164mm x 96mm |
|---|---|
| Weight | 14g |
| Operating Temperature | 0°C - 70°C (32°F - 158°F) |
| Storage Temperature | -25°C - 80°C (-13°F - 176°F) |
| Humidity | 15% – 90% |
| Warranty | 2 Years |
Look up product firmware versions, hardware revisions, and OS compatibility by entering your part number or hardware version.
