Domestic PCIe 2.0 x4 dual-port Gigabit Ethernet adapter with hardware acceleration and PTP support.
When national information security mandates require independent controllability in server deployments, finding reliable domestic networking hardware is critical. The LRES1049PT dual-port Gigabit Ethernet network adapter addresses this need for secure infrastructure.
Built on the Mucse RNP N500L-AM2 controller, this card delivers 1Gbps per port via PCIe 2.0 x4 bandwidth, ensuring low-latency transmission. Support for DPDK and SR-IOV enables efficient virtualization, while IEEE 1588 PTP synchronization ensures precise timing for industrial applications.
Ideal for servers and network security equipment, this adapter meets strict domestic compliance standards unlike generic alternatives. With an operating range of -40°C to 85°C, the LRES1049PT provides stable connectivity in demanding environments.
Based on Mucse RNP N500L-AM2 main control solution meeting national information security and independent controllability requirements.
Supports network protocol hardware acceleration to ensure smooth network operation and high-throughput data transmission.
Supports IEEE 1588 PTP clock synchronization for precise timing in industrial and data center applications.
Operates reliably in extreme environments from -40°C to 85°C, suitable for industrial automation and harsh deployments.
Supports SR-IOV and DPDK for efficient virtualization and high-performance packet processing in cloud environments.
Complete technical details for integration and deployment planning.
| Controller Chip | Mucse RNP N500L-AM2 |
|---|
| Bus Interface | PCIe v2.0 (5.0GT/s) x4 |
|---|---|
| Data Rate Per Port | 10Mbps; 100Mbps; 1Gbps |
| Connector Type | 2*RJ45 |
|---|---|
| Cable Medium | Copper |
| Fiber Type | 1000BASE-T, 100BASE-TX, 10BASE-T |
| Power Supply | PCIe |
|---|---|
| Power Consumption (Min) | 1.836W |
| Power Consumption (Max) | 3.384W |
| Protocol Support | IEEE 802.3ab, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3az |
|---|
| Feature Support (Yes) | RSS, PXE, MDI/MDI-X, DPDK, WoL, Jumbo Frames, IEEE 1588, SR-IOV, UEFI |
|---|
| Feature Support (No) | SCAN CHAIN |
|---|
| Operating Temperature | -40℃ to 85℃ |
|---|---|
| Storage Temperature | -40℃ to 85℃ |
| Storage Humidity | Maximum 90% non-condensing relative humidity at 35℃ |
| Certification | FCC, CE, RoHS |
| PCB Size | 125*68.8*1.6mm |
|---|---|
| Bracket Height | LowProfile & Full Height |
| Jumbo Frame (Max) | 9.5KB |
| RSS Queues | 8 queues per port |
| Operating Systems | Deepin 20/20.6/20.9, Zhongke Fangde Desktop/Server OS, Galaxy Unicorn V10, NeoKylin 7.6, RHEL/CentOS 7.6/7.9/8.3/8.4, Ubuntu 16.04.3/18.04.5/20.04.1/22.04.2, EmindOS, iKuairoute, ZTE New Fulcrum 5.0.5/3.2.2, OpenKylin 0.7.5, Tongxin UOS 20 |
|---|
