Connects four M.2 NVMe SSDs via PCIe 4.0 x16 slot for high-speed storage expansion.
Scaling storage capacity in a PCIe slot-limited server often means compromising between SSDs and GPUs. The LRNV95NF PCIe 4.0 x16 Quad-Port M.2 NVMe SSD Adapter solves this by enabling four high-speed drives in a single slot, eliminating the need for complex external enclosures.
With a PCIe 4.0 x16 host bus splitting into four x4 lanes, the card delivers maximum bandwidth to each connected M.2 NVMe SSD. This architecture ensures low latency and high throughput, enabling real-time data analytics and rapid file transfers without bottlenecking the CPU or memory subsystem.
Ideal for workstations and servers requiring dense, high-performance local storage, this adapter supports M.2 lengths from 2230 to 2280. By leveraging standard PCIe bifurcation, it provides a cost-effective, scalable storage solution for data centers and creative professionals seeking rapid access to large datasets.
High-bandwidth host interface compatible with PCIe 3.0/2.0/1.0 motherboards.
Connects up to 4 M.2 NVMe or AHCI SSDs via a single PCIe slot.
Includes full-height and half-height brackets for various chassis sizes.
Supports M.2 lengths 2230, 2242, 2260, and 2280.
Complete technical details for integration and deployment planning.
| Model | LRNV95NF |
|---|---|
| Bus Type | PCIe 4.0 x16 |
| Built-in Ports | 4* M.2 M-key |
| Supported Devices | 4* NVMe SSD |
| Adaptable Hard Disk Types | M.2 (PCIe, AHCI, M-Key, NGFF) |
| Device Connector | M.2 (PCIe, AHCI, M-Key, NGFF) |
|---|---|
| Host Bus | PCIe x16 |
| PCB size | 106*150*1.6 mm |
|---|
| Humidity | 15%-90% |
|---|---|
| Operating Temperature | 5℃-50℃ (41℉-122℉) |
| Storage Temperature | -25℃- 70℃ (-13℉- 158℉) |
| Feature Support (Yes) | PCIe Split Function, BIOS Slot Forking, Full-height and Half-height Brackets |
|---|
