25Gbps SFP28 optical transceiver module for 10km single-mode fiber connectivity in 5G and Ethernet networks.
When deploying 5G fronthaul or high-speed Ethernet links, maintaining signal integrity over long distances is critical for network reliability. This 25G SFP28 optical transceiver addresses connectivity challenges in distributed antenna systems and data center interconnects.
The LRTP1325-10ATL delivers data rates up to 25.78Gbps with a 10km reach over SMF-28 fiber, enabling seamless long-distance connections without repeaters. Built-in Digital Diagnostic Monitoring (DDM) allows real-time performance tracking, reducing troubleshooting time and ensuring link stability in mission-critical environments.
Ideal for 5G base stations and enterprise Ethernet backbones, this module uses DFB laser technology compliant with IEC-60825 safety standards. The LRTP1325-10ATL provides cost-effective, hot-pluggable 25G connectivity for modern optical infrastructure deployments.
Supports data rates up to 25.78Gbps for 5G fronthaul and Ethernet applications.
Enables reliable signal transmission up to 10km over standard single-mode fiber.
Built-in DDM function allows real-time monitoring of optical parameters.
SFP28 form factor supports hot-plug capability for easy installation and maintenance.
Operates on single 3.3V power supply for energy-efficient deployment.
Complete technical details for integration and deployment planning.
| Product Type | 25G SFP28 Single-mode Fiber Optical Transceiver |
|---|---|
| Form Factor | SFP28 |
| Connector Type | Duplex LC |
| Cable Type | Single-mode Fiber (SMF) |
| Max Transmission Distance | 10km |
| Data Rate | Up to 25.78Gbps |
|---|---|
| Center Wavelength Range (Tx) | 1260-1360nm |
| Launch Optical Power | -7 to +2 dBm |
| Receiver Sensitivity | -12 dBm |
| Extinction Ratio | 3.5 dB |
| Supply Voltage | 3.3V |
|---|---|
| Power Supply | Single 3.3V |
| Differential Data Input Swing | 180-700 mVpp |
| Input Differential Impedance | 90-110 ohm |
| Standards Compliance | IEEE 802.3-2005, 25G CPRI, Ethernet |
|---|
| Supported Features | Hot-pluggable, Digital Diagnostic Monitoring (DDM), RoHS 2.0 |
|---|
| Operating Temperature | |
|---|---|
| Storage Temperature | -45 to 90°C |
| Relative Humidity (Storage) | 5-95% (Non-condensing) |
| Laser Safety | Class I (IEC-60825) |
