Single-port 10G SFP+ PCIe 2.0 network adapter based on MUCSE N400L-X4 for industrial and data center use.
As a leading manufacturer of networking solutions, LR-LINK presents the LRES1050PF-SFP+, a robust single-port 10G Ethernet network adapter engineered for demanding industrial and enterprise applications. Based on our proprietary MUCSE N400L-X4 master control scheme, this adapter delivers high-speed data transmission via a 10G SFP+ interface while maintaining full compatibility with PCIe 2.0 x4, x8, and x16 slots.
This product represents a significant milestone in our commitment to technological sovereignty, achieving 100% localization of materials and chips to ensure supply chain security and independent controllability. It meets rigorous national information security strategy requirements, making it ideal for network security equipment, industrial host systems, and embedded devices where reliability is paramount.
Equipped with rich functional capabilities including network packet offloading, virtual SR-IOV support, and PXE remote network start-up, the LRES1050PF-SFP+ adapts seamlessly to diverse scenarios. Whether operating in commercial temperature ranges (0°C~50°C) or extended industrial conditions (-40°C~85°C), it provides users with an efficient, stable, and secure network connection experience.
Powered by fully localized MUCSE N400L-X4 chip ensuring security and supply chain independence.
Supports flexible 1Gbps and 10Gbps data transmission rates over SFP+ optical interfaces.
Operates reliably in extreme temperatures from -40°C to 85°C for harsh environments.
Features SR-IOV and PXE support for advanced virtualization and remote management.
Meets national information security strategies with 100% domestic material localization.
High-quality optical modules and cables for optimal compatibility with your network adapter.
Complete technical details for integration and deployment planning.
| Model | LRES1050PF-SFP+ |
|---|---|
| Bus Type | PCIe v2.0 (5.0GT/s) x4 |
| Slot Compatibility | PCIe x8, PCIe x16 |
| Connector | 1x 10G SFP+ |
| Data Rate per Port | 1G/10Gbps |
| Cable Medium | Optical Fiber |
| Fiber Type Support | 10GBase-SR, 10GBase-LR |
| Controller | MUCSE N400L-X4 |
|---|---|
| Localization | 100% Domestic Materials and Chips |
| SR-IOV | |
|---|---|
| PXE Boot | |
| Jumbo Frames | |
| RSS Queues | |
| 1588 PTP | |
| UEFI Support | |
| DPDK | |
| WoL |
| IEEE Standards | 802.1P, 802.1Q, 802.2, 802.3ac, 802.3az, 802.3x, 802.3z, 802.3ad |
|---|
| Bracket Height | Full height & Half height |
|---|---|
| Power Supply | PCIe |
| Min Power | 4.152W |
| Max Power | 4.908W |
| LED Indicators | Connection Status (Green/Orange), Transfer Status (Green Blinking) |
| Operating Temperature | 0°C to 50°C (Commercial), -40°C to 85°C (Industrial) |
|---|---|
| Storage Temperature | -40°C to 85°C |
| Storage Humidity | Maximum 90% non-condensing at 35°C |
| Compliance | FCC, CE, RoHS |
|---|
